167

21. ROLLER ASSY

ROLLER ASSY

NO.

CODE PART NAME Q`TY

1 8400A004XA E_RING_Ø6(6x12x0.8)_Fe_ZB 9

2 8200A005XA BEARING_LF_1680ZZ 8

3 801003600A ROLLER_PICK_UP_ASSY (SB3000) 1

4 801003500A ROLLER_ADF_ASSY (SB3000) 1

5 801004000A FEEDER_ROLLER_A (SB3000) 1

6 801004100A FEEDER_ROLLER_B (SB3000) 1
