179
9-2. TRANSFER_A_BOTTOM_VIEW
ASS'Y_TRANSFER_A_BOTTOM
NO.
CODE PART NAME Q`TY
1 721024400A TRANSFER_GUIDE_A_BOTTOM 1
2 741012400A BKT_GUIDE_TRANS_BOTTOM 2
3 8400E021XA SCREW_M/C_PH/SWW_M3X6_Fe_Zy 2
4-1
8400E033XA SCREW_T/P_PH_T2_Ø3X6_Fe_Zy 6
4-2
8400E034XA SCREW_T/P_PH_T2_Ø3X8_Fe_Zy 4
5 1A10X1185A SB-3000 RP1_RCV V3.0 1
6 1A10X1186A SB-3000 RP2_RCV V3.0 1
7 720713500A CAP_RP1_V 4
