SBM SB-3000 - Page 27

27
IMAGE 2 (OPTION)
■ Image Board
The part controlling on Image board as follows
Control & Processing
Counterfeit Detection: UV, MR Array, MRS L/R. IR
Fitness: CIS, CAP (Tape)
Positing sensors: RP 1 ~ 8
Output Port: Serial, Parallel, USB, RJ11 (Customer Display)
CPU
PLD
SDRAM
Image Processor
Flash
MUX
Image Processor
SDRAM
CPU
PLD
IMAGE 1
