■ MTU Board (‘CF AMP’ & ‘CAP AMP’)
MTU: Magnetic, Tape, Ultraviolet
The part controlling on MTU board is CF Amp.(for Magnetic sensor) and Cap Amp.(for tape detection)
CF AMP
Input: MR array (6 channels), MRS L/R
Role & Output: Amplifying MR signal and transferring it to the Image Board.
CAP AMP
Amplifying the CAP sensor signal and transferring it to the Image Board
CAP AMP
