Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07 7 Parameter menu
continued from previous page
Menu item
Sub-menu
item
poss. setting Notes / comments
61: Virtual 3
62: Virtual 4
63: Line voltage
OK
Supply voltage for the motor is OK
64: Control
voltage OK
The auxiliary voltage for the SMARTCON control is
OK. This function is only available if the auxiliary
voltage output is not switched on (P6.5 to 0).
65: Oil pressure
OK
The oil pressure is higher than the minimum
pressure (P6.10).
66: Oil level OK The oil level is OK.
67: pump OK
The temperature sensor in the pump motor and the
external motor protection have not tripped.
4-5
P10.2
Bin. Output
Output conf.
1
0: normal
Output 1 is set to normal, i.e. if the condition in
point P10.1 is met, Output 1 is set to HIGH (active
HIGH).
1: inverted
If the condition in point P10.1 is met, Output 1 is set
to LOW (active LOW).
2: norm. flashing
If the condition in point P10.1 is met, Output 1
starts blinking (active HIGH).
3: inv. flashing
If the condition in point P10.1 is not met, Output 1
starts blinking (otherwise it is set to HIGH).
P10.3 Bin. Output Output 2 see Output 1
P10.4 Bin. Output
Output 2
Konf.
see Output 1
conf.
P10.5 Bin. Output Output 3 see Output 1
P10.6 Bin. Output
Output 3
Konf.
see Output 1
conf.
P10.7 Bin. Output Output 4 see Output 1
P10.8 Bin. Output
Output 4
Konf.
see Output 1
conf.
P10.9 Bin. Output Output 5 see Output 1
P10.10 Bin. Output
Output 5
Konf.
see Output 1
conf.
P10.11 Bin. Output Output 6 see Output 1
P10.12 Bin. Output
Output 6
Konf.
see Output 1
conf.
P10.13 Bin. Output Output 7 see Output 1
P10.14 Bin. Output
Output 7
Konf.
see Output 1
conf.
P10.15 Bin. Output Output 8 see Output 1
P10.16 Bin. Output
Output 8
Konf.
see Output 1
conf.
CAUTION: When using the parameters torque-dependent OPEN or torque-dependent CLOSED
(see section 7.1, page 24, items P1.3 and P1.4), the actuator will only be open or closed when
the set torque and the associated end position is reached. If the end position is not reached,
a torque error is reported (see section 6.2.2, page 19).
33
