Section 6 - Service
HV-18 revised 11/18 SCHWARZE HYPERVAC 103
SK-2428 - DIODE & RESISTOR CAP
This D rawing is the prop erty of
SCHWARZE IN DUSTRIES INC. T his
documen t will no t be disc losed, co pied,
distrib uted without expressed written
co nse nt from S CHW ARZ E INDUST RIE S
INC.
Drawn by RAG
RAG
SCHWARZE INDUSTRIES INC.
DIODE & RESISTOR CAP SERVICE
INFORMATION
SI ZE FSCM NO DWG NO REV
C SK-2428 B
SCA L E
NONE
SH EE T
14 OF 14
D
C
B
A
4 3 2 1
D
C
B
A
4 3 2 1
FOR DIODES:
D1 – SHAKER HOPPER DIODE
D2 – WATER PUMP #1 DIODE
D3 – SCREEN SHAKER DIODE
1 2
DT04-2P-RT01
12
DEU T SC H
DTM04-2P
P006
FOR RESISTORS:
R2 – J1939 SERVICE PORT (NO RESISTOR CAP)
R4 – CAN OPEN TERMINATING RESISTOR
