Display Module - Main Screen Identification
1.
13
12
1
2
3
4
5
6
7
11
10
9
8
HOPPER SHAKER BUTTON*
2. THROTTLE UP FOR AUX ENGINE
3. THROTTLE DOWN FOR AUX ENGINE
4. LEAF DOOR ACTIVATION BUTTON
5. DUST STRIPPER BUTTON
6. ARROW KEYS AND SELECT BUTTON
7. MESSAGE WINDOW
8. FRONT SPRAY BAR*
9. HOPPER SPRAY BAR*
10. MOTOR SPEED CONTROL*
11. PITCH CONTROL*
12. SWEEPER UNIT GAUGES
13. OPERATIONAL ICON SCREEN
NOTE
Some Monitor Side buttons may have hidden switch icons. Press once to expose switch icon on
monitor.
NOTE
Switches with visible icons only require one press to activate. Some buttons have several selections
to cycle through.
