Section 6 - Service
HV-18 revised 11/18 SCHWARZE HYPERVAC 109
Spare Parts List
PART # QTY MAINTENANCE/WEAR PARTS-APPROX 1000 HOURS NOTES/EXPLANATION
20096 BEARING
20391 SUCTION STRAINER DUST SUPPRESSION
203C98 SPRAY TIP, INTAKE ASSEMBLY DUST SUPPRESSION
20407 SPRAY TIP FILTER, 100 MESH DUST SUPPRESSION
20408 SPRAY TIP BODY, WATER SYST
20420 SPRAY TIP RETAINER NUT, PVC WATER SYSTEM
20425 SPRAY TIP FLOODING JET DUST SUPPRESSION
20441 SPRAY TIP BRASS DUST SUPPRESSION
20504 BUSHING, 1" BORE
20749 BROOM SEGMENT SET - SIDE BROOM SIDE BROOM/BRUSHES
21033 SUCTION HOSE NOZZLE HEAD
21687 INTAKE HOOD, AIR
22431 SPRAY TIP BODY, DUST SUPPRESSION
22542 SPRAY TIPS, YELLOW DUST SUPPRESSION
23229 BEARING
23854 PULLEY
24044 HOSE CLAMP MISC
24046 SEAL, INTAKE FOAM MISC
24089 DC PUMP HYDRAULIC
26311 BREATHER FILLER
27454-36 HOPPER DRAIN HOSE
28555 RETURN FILTER HYDRAULIC
28647 FILTER STRAINER HYDRAULIC
29138 LOCKING T LATCH
3003920 HAND HOSE HANGER
3005019 FAN HOUSING LINER POWER MODULE
3005441 FRONT DEFLECT STRIP
3005462 CENTER BROOM DEFLECTOR
3005597 CENTER BROOM STRIP SEGMENT MISC
301058 DRAG ARM LOWER RHS
301059 DRAG ARM, UPPER RHS
301140 DRAG ARM LOWER LHS
301141 DRAG ARM UPPER LHS
301226 NOZZLE STOP, LHS
301272 NOZZLE SKID LHS
301248 FRONT DEFLECTOR WELDMENT
301255 SKID, NOZZLE NOZZLE HEAD
5206385 SEAL, FAN POWER MODULE
5222279 DOOR LATCH PIVOT PIN
