Schweitzer Engineering Laboratories SEL-587Z - Figure 7.2 SHO L Command Sample Display; Figure 7.3 SHO P F Command Sample Display; Figure 7.4 SHO R Command Sample Display

7.17
Date Code 20020903 SEL-587Z Instruction Manual
ASCII Command Reference
Command Definitions
=>SHO L <Enter>
SELogic Control Equations:
TR1 =87A1 + 87B1 + 87C1 + 50A1 + 50B1 + 50C1
TR2 =0
TR3 =0
ULTR1 =!87A2 * !87B2 * !87C2 * !50A2 * !50B2 * !50C2
ULTR2 =1
ULTR3 =1
51PTC =1
51ATC =1
51BTC =1
51CTC =1
51GTC =1
51QTC =1
52A =0
CL =0
ULCL =TRIP1
ER1 =87A1 + 87B1 + 87C1
ER2 =87A2 + 87B2 + 87C2
Press RETURN to continue
SV1 =0
SV2 =0
SV3 =0
SV4 =0
SV5 =0
SV6 =0
SV7 =0
SV8 =0
SV9 =0
SV10 =0
SV11 =0
SV12 =0
SV13 =0
SV14 =0
OUT1 =TRIP1
OUT2 =TRIP1
OUT3 =SV5T + SV6T
OUT4 =0
DP1 =0
DP2 =0
Press RETURN to continue
DP3 =0
DP4 =0
DP5 =0
DP6 =0
DP7 =0
DP8 =0
Figure 7.2 SHO L Command Sample Display.
=>>SHO P F <Enter>
PROTO = SEL
SPEED = 2400 BITS = 8 PARITY = N
STOP = 1 T_OUT = 15 AUTO = N
RTSCTS = N FASTOP = N
=>>
Figure 7.3 SHO P F Command Sample Display.
=>SHO R <Enter>
Sequential Events Recorder trigger lists:
SER1 =87A1 87A2 87B1 87B2 87C1 87C2
SER2 =50P1 50A1 50A2 50B1 50B2 50C1 50C2
SER3 =51PT 51AT 51BT 51CT 51GT 51QT
Figure 7.4 SHO R Command Sample Display.
