5.3
Date Code 20020903 SEL-587Z Instruction Manual
Setting the Relay
Settings Changes Via the Front Panel
Settings Changes Via the Front Panel
The relay front-panel {SET} pushbutton provides access to the relay and port
settings only. Use the corresponding relay and port settings sheets that follow
in this section when making these settings via the front panel. Refer to
Figure 8.1 on page 8.2 in Section 8: Front-Panel Interface for information
about front-panel communications.
