Date _______________
Date Code 20020903 SEL-587Z Instruction Manual
5 of 11SEL-587Z Settings Sheets
Relay Settings (SET Command)
SV8 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps) SV8DO =
SV9 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV9PU =
SV9 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV9DO =
SV10 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV10PU =
SV10 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV10DO =
SV11 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV11PU =
SV11 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV11DO =
SV12 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV12PU =
SV12 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV12DO =
SV13 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV13PU =
SV13 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV13DO =
SV14 Timer Pickup (0–54000.000 cycles in 0.125-cycle steps)
SV14PU =
SV14 Timer Dropout (0–54000.000 cycles in 0.125-cycle steps)
SV14DO =
Other System Parameters
Nominal Frequency (50, 60 Hz) NFREQ =
Phase Rotation (ABC, ACB)
PHROT =
Date Format (MDY, YMD)
DATE_F =
