Section 05 ENGINE (4-TEC)
Subsection 07 (LUBRICATION SYSTEM)
SMR2003-019_05_07A.FM 05-07-17
Inspection
If O-rings and rubber rings are brittle, cracked or
hard, replace them.
Clean all contact surfaces of oil separator.
Check and clean the oil and blow-by channels for
dirt and other contaminations.
Installation
For installation, reverse the removal procedure.
Pay attention to the following details.
1. Screws M6 x 25
2. Screws M6 x 85
Apply grease on O-rings and rubber rings.
Torque screws to 10 N•m (88 lbf•in). Apply Loctite
243 (blue) on threads.
1
R1503motr119A
2
