Section 12 ELECTRICAL SYSTEM
Subsection 03 (CHARGING SYSTEM)
12-03-6 SMR2003-036_12_03A.FM
STATIC TEST: INSULATION
1. Disconnect the magneto wiring harness connec-
tor.
2. Install the 4-pin magneto harness adapter (P/N 295
000 131) to the magneto wiring harness. Leave
wiring harness side disconnected.
3. Insert multimeter positive (+) probe to the
BLACK/YELLOW wire of the 4-pin magneto har-
ness adapter.
4. Ground the multimeter negative (-) probe to the
engine or the stator iron core and note the read-
ing.
5. Repeat test with the other BLACK and RED/
BLACK wires of the 4-pin magneto harness adapt-
er.
NOTE: There should be no continuity (infinity) be-
tween the stator insulated coils and ground. If
there is a reading, the stator coils and/or the wir-
ing from the coils is grounded and needs to be
replaced or repaired.
DYNAMIC TEST
1. Disconnect the magneto wiring harness connec-
tor.
2. Install the 4-pin magneto harness adapter (P/N 295
000 131) between connectors.
3. Connect test probes of the multimeter to the
BLACK/YELLOW and RED/BLACK wires of the
4-pin magneto harness adapter.
4. Set multimeter to Vac scale.
5. Start and rev engine to 3500 RPM. The obtained
value should be between 45 and 70 Vac.
6. Repeat test with the BLACK wire and either the
RED/BLACK or BLACK/YELLOW wires of the
4-pin magneto harness adapter.
7. If the stator is out of specification, replace it.
BATTERY
Troubleshooting
Removal
SYMPTOM: DISCHARGED OR WEAK BATTERY
CAUSE REMEDY
1. Battery posts and/or
cable terminal
oxidized.
Clean and coat with
dielectric grease.
2. Loose or bad
connections.
Check wiring and
connector cleanliness,
damaged or short circuit.
3. Faulty battery
(sulfated, doesn’t
keep a full charge,
damaged casing,
loose post).
Replace.
4. 20 amp fuse(s) burnt
or faulty rectifier.
First check fuse.
If it is in good condition,
check rectifier/regulator.
5. Faulty battery charging
coil (or stator).
Replace.
WARNING
Battery BLACK negative cable must always
be disconnected first and connected last.
Never charge or boost battery while installed
in watercraft.
