Section 05 ENGINE MANAGEMENT (DI)
Subsection 03 (COMPONENT INSPECTION AND ADJUSTMENT)
SMR2000-051-05-03A.FM 05-03-35
Manifold air
temperature
sensor (MATS)
AMP no. 4 16 and 19 WH/GY and BK/WH 2280 - 2740 ohms
Water temperature
sensor (WTS)
AMP no. 4 9 and 11 TA/OR and BK/OR 2280 - 2740 ohms
Manifold air
pressure sensor
(MAPS)
AMP no. 3
Pin 3 and pin 1
of MAPS
PU/BL
0 ohm (continuity)
Pin 6 and pin 3
of MAPS
WH/BL
Pin 7 and pin 2
of MAPS
BK/BL
Exhaust gas
temperature (EGT)
AMP no. 4 10 and 12 TA/GY and BK/TA 2280 - 2740 ohms
Knock sensor (KS) AMP no. 4 2 and 17 BK/BL and YL/BL 5 Mohms
Rave solenoid (RS) AMP no. 4 20 and 23 PU/GY and BK/GY 24 ohms
Ignition coil MAG
AMP no. 3 21 and 22 RE/GN and WH/GN
.45 - .55 ohms
primary winding
—
Coil terminal C
and coil post
—
6800 - 10200 ohms
secondary winding w/o
high tension leads
Ignition coil PTO
AMP no. 3 20 and 23 RE/BL and WH/BL
.45 - .55 ohms
primary winding
—
Coil terminal C
and coil post
—
6800 - 10200 ohms
secondary winding w/o
high tension leads
High tension leads
RX DI models
MAG ——5700 ohms lead alone
PTO — White tape 4300 ohms lead alone
High tension leads
GTX DI models
MAG ——5700 ohms lead alone
PTO — White tape 4900 ohms lead alone
COMPONENT CONNECTOR
TERMINAL
NUMBER
WIRE COLOR VALUE
