Selco EB 70 - General View and Main Parts


&KDSWHU
0DLQ3DUWVDQG)RUHVHHQ8VHV
BIESSE S.p.A. Woodworking Machinery
(l127h024.fm-141101)
 *HQHUDO9LHZDQG0DLQ3DUWV
$ %DVH; this is the machine’s bearing structure.
% 3DQHO6XSSRUW; this is used to support the piece during the loading and unloading phases.
& 2SHUDWLQJ6HFWLRQ; this is used to cut the piece. For further details, please go to the
paragraph “Operating Section” on page 1 - 4.
'- &RQWURO3DQHO; this is used to control the machine’s operation. For more information, see
Chapter 3. “Controls and Signalling Devices”.
( 6LGH6WRS; this is the reference point for the right- or left-hand side of the piece, according to
the position of the stop itself.
) 5HDU&ROOHW6WRSRU3XVKLQJ'HYLFH: this is the reference point for the rear side of the
piece. The stop is also equipped with a collet that locks the piece in order to prevent it from
losing its point of reference during movement.
* :KHHO3DQHO6XSSRUW: this supports the piece, allowing it to slide easily.
+ 3UHVVHU: this presses down on the upper side of the piece.
- 6LGH3XVKHU this pushes the piece to bring it up against the stops.
*
+
$
-
%
(
'
