Selco EB 70 - Making an Immediate Cut Using Fast Programming; Making Cuts in Sequence Using Fast Programming


&KDSWHU
0DFKLQLQJ
BIESSE S.p.A. Woodworking Machinery
(l133h014.fm-141101)
0DNLQJDQ,PPHGLDWH&XW8VLQJ)DVW3URJUDPPLQJ
This machining mode can be used through the MANUAL CUTS page of the numerical control (to
open this page, press F2 from the main menu), and is usually used to rapidly program and make
one or more cuts.
To carry out this type of machining proceed as follows:
1. Make sure that the start button (green) on the button pad (ref. B1, page 3 - 3), is lit.
2. Press F5 from the MANUAL CUTS page to enable the ejection and new cycle control.
3. Press the cycle start button (white) on the main button pad (ref. B6, page 3 - 3). The carriage
that drives the pushing devices and the rear collet stops will move into the proximity of the
cutting area. For this reason, if there are any pieces on the wheel supports, these will be
unloaded.
4. Load the piece.
5. Press the cycle start button (white) on the main button pad (ref. B6, page 3 - 3). The collets
on the rear stops will lock the piece into place.
6. Press the blade start button (white) on the same button pad (ref. B3v 3 - 3).
7. Press one of the immediate cut keys on the PLC keyboard to choose and enable (ref. E8,
E10, E12, page 3 - 4), the type of immediate cut required (short, long, complete).
8. From this point onwards the machine will immediately carry out any command enabled from
the MANUAL CUTS page. The first command usually enabled is a panel measure and trim
cut. In this way the machine automatically effects all of the movements required to calculate
the dimensions of the piece and to make the trim cut. Subsequently the length and quantity of
cuts must be selected and lastly, the ejection and new cycle control should be enabled. For
more detailed information about how to use the controls on this page, see the Software User’s
Manual.
0DNLQJ&XWVLQ6HTXHQFH8VLQJ)DVW3URJUDPPLQJ
This machining mode is used from the SEQUENCE MODE page of the numerical control (to open
this page press F3 from the main menu), and it is usually used to rapidly program and make a
sequence of cuts for a given quantity of pieces.
To carry out this type of machining proceed as follows:
1. Make sure that the start button (green) on the main button pad (ref. B1, page 3 - 3), is lit.
2. Press F1 from the SEQUENCE MODE page to enable the required program.
3. Press the blade start button (white) on the main button pad (ref. B3, page 3 - 3).
4. Press the cycle start button (white) on the same button pad (ref. B6, page 3 - 3).
