Selco EB 70 - Blade Belt Replacement


&KDSWHU
5HSODFHPHQWVDQG$GMXVWPHQWV
BIESSE S.p.A. Woodworking Machinery
(l138h009.fm-141101)
 %ODGH%HOW5HSODFHPHQW
1. Turn the blade change selector (key) on the
main button pad to the right (ref. B5, page
3 - 3), and then remove the key. The
motors switch off, the carriage moves to a
pre-set position and a system which, after a
lapse of time, automatically releases the
blade A access hatch, is enabled.
2. Open the blade $ access hatch once the
lamp on the pushing device selector
(yellow) is lit; this selector is located on the
main button pad (ref. B8, page 3 - 3).
3. Switch off the machine.
4. Loosen the % nuts DQGRQHRIWKH&
VFUHZV(it is unimportant whether the
chosen screw is on the left-hand side or on
the right-hand side), then remove the cover
'.
5. Remove the blades as described in the
paragraph 8.1 “Blades Replacement” on
page 8 - 1.
6. Remove the casing (.
7. Remove the suction pipe ).
8. Remove the casings * and +.
'
&
%
$
(
)
*
*
+
+
