Electrical Safety Test
To test the basic electrical safety of the Eclipse AC Power Supply, SeQual recommends using an LKG-
601 Electrical Safety Analyzer (Netech Corporation, Hicksville, NY) or equivalent to verify that the current
leakage to ground is within appropriate limits. This is required only for the Eclipse Oxygen System,
PN 5701 that utilizes the Hospital Grade Power Cord.
1. Plug the AC Power Supply into the electrical safety analyzer. Disconnect the AC Power Supply
from the Eclipse unit.
2. Plug the electrical safety analyzer into a wall outlet.
3. Follow the analyzer manufacturer’s instructions for measuring both the forward and reverse earth
leakage current only. Verify that forward and reverse-current leakage to ground is <
250 µA
(100/115VAC applications) and <
500 µA (220/240VAC applications).
4. Disconnect the AC Power Supply from the electrical safety analyzer.
5. If the AC Power Supply measures leakage current greater than the criteria in step 3, please
return it to SeQual for service.
Cleaning the Eclipse
Clean inside the unit, as needed, using a small vacuum cleaner or brush to remove any accumulation of
dust or debris prior to attaching the covers. After reinstalling the cover, verify that the rubber gasket is
installed correctly.
Use mild detergent solution to clean the cabinet, control panel and power supplies. Turn OFF the Eclipse
and disconnect from AC or DC power before any cleaning or disinfection activity. DO NOT
spray the
cabinet control panel or power supplies. Use a damp (not soaking wet) cloth or sponge. Spray the cloth
or sponge with a mild detergent solution to clean the cabinet and power supplies. To disinfect the
Eclipse, use Lysol® Brand II disinfectant. Proceed as directed by the manufacturer.
WARNING:
Unplug Power Cords, AC or DC Power Supplies before cleaning
the exterior cabinet. DO NOT
use denatured alcohol or apply
liquid spray or aerosol cleaners.
