Alarm Conditions and Alarm Codes
Use the table below to decode Eclipse alarm conditions. If other alarm codes are displayed by the
Eclipse, contact SeQual for assistance.
Note: The following table is intended as a guide for the provider
, not the user.
Condition
Green
Indicator
Yellow
Indicator
Red
Indicator
Audible
Alarm
Alarm
Code
What to do
“Warming Up.
Please Wait.”
On On On Off 04
Wait. The system typically takes
3 - 5 minutes to reach specified
performance.
TYPICAL
CONDITIONS
“3.0”
(or flow setting)
On Off Off None 00
Nothing. The system is operating
properly at the specified flow rate.
“Low Power
Cartridge”
On Blinking Off Beeps 10
Plug into external power or
replace with a charged Power
Cartridge.
“Warm Power
Cartridge”
On Blinking Off Beeps 02
Plug into external power or
replace with a charged Power
Cartridge.
“9-Volt Battery” Off Off Off 3 Beeps
The internal 9-Volt battery needs
replaced.
“O
2
Concentration
< 85%”
Off Blinking Off Off 08
Continue Use. Check or clean air
intake filter. If condition persists,
service is required.
“O
2
Concentration
< 70%”
Off
Off Blinking Beeps 04
Continue Use. Check or clean air
intake filter. If condition persists,
service is required.
“Flow Rate
Error/Blocked
Flow”
Off Blinking Off Beeps 20
Check tubing and/or humidifier for
obstruction. Check/clean air
intake filter. If condition persists
past 10 minutes. If condition
persists, service is required.
“Cannot Charge
Power Cartridge”
Off On Off Off 01
Instruct patient to seek an
external power source. Remove
Power Cartridge and allow to cool
to room temperature. If Power
Cartridge malfunction persists,
service is required.
UNIT NEEDS ATTENTION
“No Inspiration
Detected” (in
Pulse Flow Mode
only)
On On Off Off 20
Make sure tubing does not
exceed 7 ft (2.1m) when using
Pulse Flow Mode. An alert
(yellow LED) will begin after 45
seconds if no inspiration is
detected. If no inspiration is
detected 15 seconds after that,
the Eclipse will activate a single
beep and will automatically switch
to Continuous Flow Mode
operation.
