SeQual Technologies Eclipse 2 - Pulse Mode Specifications; Power Accessory Specifications; AC Power Supply

9
Audible Alarm Indicators Loss of Power/Hot Power Cartridge
Low Power Cartridge/Warm Power Cartridge
Low Oxygen Output
O
2
Flow Outside Normal Limits
Unit Malfunction
Back-Up Alarm Power 9V Internal Battery
Filters Air Inlet, HEPA, Compressor Intake
Device Classification IEC Class I, Type B Applied Part, IPX0
Pulse Mode Specifications
Pulse Settings 1.0 to 6.0, in increments of 0.5
Trigger Sensitivity Adjustable between settings of 1 (most sensitive) to 6 (least sensitive)
Trigger Criteria
• Cannula pressure has dropped below the trigger point (typically
between 0.15 – 0.45 Cm of H
2
O of negative pressure)
• At least 1¼ seconds has passed since the last pulse began
Minimum time between
breaths
1.25 seconds (max. 3 consecutive breaths)
Response to Missing
Breaths
• Yellow LED is activated if no inspiration has been detected after 45
seconds.
• Switch to Continuous Mode if no inspiration has been detected for
60 seconds with an audible alarm.
Bolus Volume and Breath Rates
AC Power
Supply and
Power Cartridge
10 Amp
Switch Setting
DC Power Supply
15 Amp
Switch Setting
DC Power Supply
Pulse
Flow
Setting
Bolus Size
(± 15%)
Min
Breath
Rate
Max Breath
Rate
Max Breath
Rate
Max Breath
Rate
1.0 16 6 40 40 40
2.0 32 6 40 40 40
3.0 48 6 40 40 40
4.0 64 6 39 31 39
5.0 80 6 31 25 31
6.0 96 6 26 20 26
Power Accessory Specifications
AC Power Supply
Input Voltage 100-240VAC, 50-60 Hz
Input Power 245-260 VA
Output Voltage 28 VDC
Output Power 200W
