SeQual Technologies Eclipse 2 - Remove and Replace the Buzzer Wire Harness; Figure 40: Bonding the Buzzer to the Case; Figure 41: Buzzer Installation

77
Remove and Replace the Buzzer Wire Harness
1. Unplug the buzzer from the Control Module PC Board.
2. Remove the Control Module.
3. To remove the buzzer from the case, cut the cable tie, grasp the buzzer body with a pair of pliers
and rotate the buzzer to break the adhesive joint.
4. To install a new buzzer, apply a ring of cyanoacrylate adhesive (Super Glue) around the inlet hole
as shown in Figure 40.
A
pply adhesive
Figure 40: Bonding the Buzzer to the case.
5. Place buzzer as shown in figure 41. Ensure that the buzzer opening is centered over the grill
hole. Hold in place until adhesive cures.
Figure 41: Buzzer Installation.
