6.3 TRANSDUCER UNITS PARTS LIST
See Figures 6.2, 6.3, 6.4 and 6.5.
Item Description 1131 1132 1133
1 Inner Box - Front Assembly 01131913 01191909 01131913 1
2 Magnet Frame Assembly S1131901 S1191911 01131931 2
3 Inner Box - Rear Assembly 01131914 01132924 01133905 3
4 Thermistor 2651-6330 2651-6330 2651-6330 4
5 LED Assembly 01100941 01191907 01100941 5
6 Photocell 4931-7174 4931-7174 4931-7174 6
7 Measuring Cell (Standard) 00325000 00364000 00325000 7
(Option) 00364000 - 00364000
8 Zero Adjusting Screw 00500417 00500417 00500417 8
9 Temperature Sensor
Assembly
01130932 01130932 01130932 9
10 Heater/Heater Assembly 2666-2318 01191904 01133903 10
(Option for 110V Supply -
1132 only)
- 01191917 -
11 Heater Housing - 01132922 01133901 11
12 Terminal Box Assembly - 01131901 01131901 12
13 O-Ring BS006 (part of kit) 01131984 01132982 01131984 13
14 Inlet Tube (part of kit) 01131984 01132984 01131984 14
15 Outlet Tube (part of kit) 01131984 01132984 01131984 15
16 O-Ring BS006 (part of kit) S1131990 S1132990 S1131990 16
17 Thermal Insulation 3921-5994 3921-5963 3921-5994 17
18 Seal Plate 01131436 - 01131436 18
19 Cable Form 01131934 01191913 01131934 19
21 Conduit Spacer 01131419 - - 21
22 O-Ring BS212 (part of kit) S1131990 S1132990 S1131990 22
23 O-Ring BS209 (part of kit) S1131990 S1132990 S1131990 23
24 O-Ring BS210 (part of kit) S1131990 S1132990 S1131990 24
25 Gasket (part of kit) - S1132990 - 25
26 Heat Transfer Interface - 01191912 - 26
27 Conduit Spacer 01131413 01131413 01131413 27
28 Thermal Fuse Assembly Heat
Transfer Block and Thermal
Switch (1132 only)
2536-1012
-
-
01132923
-
-
28
To Next Page
