Servomex SERVOPRO Plasma User Manual

Plasma Gas Analyzer
10 02001001A_9
2.3 Electrical data
Electrical supply
Voltage:
100 - 120 Vac / 230 - 240 Vac, 50 to 60 Hz
(± 10% maximum fluctuation)
(1)
Fuse rating / type:
Two fuses 1 amp / 250 V, Type “F”,
Breaking capacity 1.5kA @ 250 V AC
miniature fuses 5 x 20 mm
Maximum power consumption:
45W
Interface signal relay ratings:
30 Vrms, 42.4 V peak or 60 Vdc/ 1A
mA output (active)
Maximum load resistance:
600 Ω at 20 mA DC
Isolation voltage (to earth):
750 VDC or AC
Normal sample measurement:
4mA to 20 mA
Fault condition:
4 mA or 20 mA (can be set high or low)
(1) The analyzer is supplied configured for operation with one of these voltage ranges. You must specify the
voltage range when you order the analyzer.
2.4 Sample Gases

The sample gases must be, clean, non-corrosive, free from oil and
condensates and compatible with the materials listed in Appendix 1
Flow rate:
25 to 150 ml min-1
Pressure:
27.6 to 55.2 kPa gauge (max)
(5 to 10 Psig(max))
Dew point:
5 °C below ambient temperature (minimum)
Temperature:
5 to 40 °C
Particulate size:
< 2 µm (2 micron)
CAUTION
To retain the CE mark, do not operate above 70kPa (10psig)
