Plasma Gas Analyzer
17 02001001A_9
4.2.2 Connect the electrical supply
WARNING
Only use the power supply cord provided with the unit.
CAUTION
Ensure that the analyzer is suitable for use with your electrical supply voltage
and frequency. If the analyzer is not suitable, the analyzer may not operate
correctly, or it may be damaged when you operate it.
To comply with the relevant safety requirements the cables carrying mains power
and connected to the analyzer shall be approved to:
For EU: IEC 60227 or IEC 60245 and be designated H05VV-F.
For North America: UL817 or CSA C22.2 No. 21 and be designated SJT.
Ensure that the cables that you connect to the analyzer are routed so
that they do not present a trip hazard.
The analyzer is supplied with an electrical supply cable, configured for your electrical
supply. Connect the electrical supply to the analyzer as follows:
Fit the IEC plug on the electrical supply cable provided to the electrical supply socket
on the rear of the analyzer (Figure 2 item 3).
Check the earth (ground) continuity between your electrical supply outlet earth
(ground) and the SH (ground) terminal on the rear of the analyzer (Figure 2 item 7) or
exposed metal work.
Connect the electrical supply cable to your electrical supply outlet.
