Plasma Gas Analyzer
30 02001001A_9
5.3 Configuration
Pressing F1 from the MAIN MENU will bring you to the CONFIGURATION MENU.
The CONFIGURATION MENU prompts you to enter three different parameters:
5.3.1 Auto ranging
"Auto ranging". Choosing “F1” "yes" allows the analyzer to "switch" automatically between
the three possible ranges. “F1” "toggles" the selection between "yes" and "no".
Figure 17 - CONFIGURATION MENU
5.3.2 Sample flow
Enter your desired sample flow value simply by using the number keys and confirming your
value with the "E" key for enter. The allowed numeric value for the flow is any integer
number between 0 and 200. The flow unit is cc/m.
The new input value becomes immediately active and the flow valve will react accordingly.
5.3.3 Analogue output mode
By pressing the "F2" key, the analogue 4 - 20 mA output will be in either "track" or "hold" mode.
Hold mode: "hold" will maintain analogue output at last "on run" gas value when exiting run
mode.
Track mode: “track" will cause analogue output to track input gas value during all modes.
Pressing the"F3" key will bring you to the second page of the CONFIGURATION MENU.
<<CONFIGURATION MENU>> F3:NEXT
F1:Automatic ranging? (Yes/No):YES
Sample flow set point(0-200CC):25
F2:Analogue output (Hld/Trk):HOLD F4:RET
