Plasma Gas Analyzer
7 02001001A_9
1.3.2 02001 Analyzer layout
Key
Description
1.
Keypad
2.
LCD display
3.
Power inlet
4.
Gas connections
5.
(Service port)
6.
RS-232 port
7.
IO Connector
Figure 1 - FRONT OF THE ANALYZER
Figure 2 - REAR OF THE ANALYZER
1
2
4
6
5
3
7
