Plasma Gas Analyzer
33 02001001A_9
Figure 21- DISPLAYED WHEN ENTERING SPAN VALUE
The analyzer will automatically select the appropriate range based on the span value entered.
When you have entered a value and pressed the "E" key (E for enter), the processor checks the
format, evaluates it and validates it. If everything is OK, your value will be redisplayed in the
actual value field. If not, the value is rejected, the input field is cleared and the actual value is left
unchanged.
If you made an error when entering your value, just press enter and start over.
Once you have entered the zero and the span values, select “F3” to get the CALIBRATION
SUB-MENU.
The following figure shows this sub-menu:
Figure 22 - CALIBRATION SUB MENU
