Servomex SERVOPRO Plasma User Manual

Plasma Gas Analyzer
78 02001001A_9
Status
Acceptable output
Description
RANGE
RA-LO 0- 10 ppm
RA-MED 0- 100 ppm
RA-HI 0- 1000 ppm
RF-LO 0- 10 ppm
RF-MED 0- 100 ppm
RF-HI 0- 1000 ppm
RA-LO: Instrument is in the low range and
auto ranging
RA-MED: Instrument is in the medium range
and in auto ranging
RA-HI: Instrument is in the high range and in
auto ranging
RF-LO: Instrument is in the low range and in
fixed range
RF-MED: Instrument is in the medium range
and in fixed range
RF-HI: Instrument is in the high range and in
fixed range
They have to end with the range limits “0- xxxx
ppm”
Example ranges are in the middle column, the
top limit can be any integer number.
ALARM 1 STATUS
AL-1 ON
AL-1 DISABLED
Status of alarm 1
ALARM 2 STATUS
AL-2 ON
AL-2 DISABLED
Status of alarm 2
ANALYZER MODE
A
S
Z
A, analyzer is in analyze/sample mode
S, analyzer is in span mode
Z, analyzer is in zero mode
MODEL NUMBER
8 characters
Model number is 8 characters long or less. It
can be letters or numbers.
SERIAL NUMBER
8 characters
Serial number is 8 characters long or less. It
can be letters or numbers.
<LF><CR><NULL>
<LF><CR><NULL>
Each output string must end with
<LF> Line feed
<CR> Carriage return
<NULL> Null character
in that order
