STAPLE CARTRIDGE REPLACEMENT
(when the finisher (MX-FN13) is installed)
When the staple cartridge runs out of staples, a message will appear in the operation panel. Follow the procedure
below to replace the staple cartridge.
Replacing the staple cartridge
1
Open the cover.
2
While pressing the lever over to the
left, slide the finisher to the left until it
stops.
Gently slide the finisher
until it stops.
3
Lower the staple case release lever
and remove the staple case.
Pull the staple case out
to the right.
4
Remove the empty staple cartridge
from the staple case.
5
Insert a new staple cartridge into the
staple case as shown.
Push the staple cartridge
in until it clicks into place.
6
Replace the staple case.
Push the staple case in
until it clicks into place.
7
Slide the finisher back to the right.
Gently slide the finisher
back to the right until it
locks into its original
position.
8
Close the cover.
Make a test print or copy in staple sort mode to verify that stapling takes place correctly.
Note
