141
PERIPHERAL DEVICES AND SUPPLIES
6
500-SHEET PAPER FEED UNIT/
2 x 500-SHEET PAPER FEED UNIT
These paper feed units provide the convenience of increased paper capacity for the machine and a greater choice of
paper sizes readily available for copying.
The MX-DE10 contains one 500-sheet paper tray and the MX-DE11 contains two 500-sheet paper trays.
Part names
Specifications
MX-DE10 MX-DE11
Paper
Size B5 to A3 (8-1/2" x 11" to 11" x 17")
Weight 56 g/m
2
to 105 g/m
2
(15 lbs. to 28 lbs.)
Paper
capacity
Upper tray
500 sheets (80 g/m
2
(21 lbs.) 500 sheets (80 g/m
2
(21 lbs.)
Lower tray
— 500 sheets (80 g/m
2
(21 lbs.)
Weight Approx. 7.0 kg (15.5 lbs.) Approx. 13.2 kg (29.2 lbs.)
Dimensions
596 mm (W) x 498 mm (D) x 102 mm (H)
(23-15/32" (W) x 19-39/64" (D) x 4-1/64" (H))
596 mm (W) x 498 mm(D) x 202 mm (H)
(23-15/32" (W) x 19-39/64" (D) x 7-61/64" (H))
Power supply Drawn from the machine
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification
changes for product improvement without prior notice. The performance specification figures indicated are
nominal values of production units and there may be some deviations from these values in individual units.
Tray
500-SHEET PAPER FEED UNIT
(MX-DE10)
Side cover
2x500-SHEET PAPER FEED UNIT
(MX-DE11)
Side cover
Tray
Note
