Shimadzu GC-2014 Series User Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
15
221-70051-91 221-70050-90
GC-2014ASSY,100V COMMON ASSY
221-70052-91 221-49613-91
OVEN HEATER ASSY,100V COLUMN OVEN HEATER ASSY, 100V
115V:221-70052-92 115V:221-49613-92
230V:221-70052-34 230V:221-49613-34
221-43695-91
PT SENSOR ASSY, 17A PLUS
221-43696-91
THERMOCOUPLE,
221-70072-91 WITH CONTACTS, 17A+
MOTOR ASSY,100V
115V:221-70072-92
230V:221-70072-34
221-48460-92
POWER UNIT,2014 100V
115V:221-48460-92
230V:221-48460-39
221-70706-91 221-46228-91
FILTER ASSY,100V AC CORD, GC2010, 100V
115V:221-70706-91 115V:221-46228-91
230V:221-70706-34 230V:221-46228-98
221-70726-91
AC PS CABLE ASSY, 100V
115V:221-70726-91
230V:221-70726-34
075-00072-04
FILTER, ZAG2230-11S (100V/115V)
075-00069-04
FILTER, MBS-1220-22 (230V)
072-61022-05
CORD STOPPER, JPG-16B (100V/115V)
072-61012-04
BUSHING, FLEX, LTF13.5 (230V)
221-46229-93
PS CABLE, STD, GC2014
221-46230-91
PS CABLE, DC, STD
074-80654-77
POWER SUPPLY, VS100B-24 (100V/115V)
074-80427-61
POWER SUPPLY, LEA100F-24
201-31219-01
BLOCKING RUBBER TUBE
221-28247
FAN
221-12949
COOLING FAN, 6125CCW
①
(A)

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
