Shimadzu GC-2014 Series User Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
16
221-70050-90 221-70055-91 221-70056-91
COMMON ASSY OVEN ASSY OVEN UNIT ASSY
221-70057-91 221-49480
AIR-SUPPLY/EXHAUST ADDITIONAL PROCESSING,
PIPE ASSY GEAR, MOTOR
221-47652
FLAP MOTOR
221-70060-91 221-70254-91
RIGHT PLATE, PCB DET I/F, GC-2014
GC- 20 1 4
221-47632-92 221-45737-91
CPU UNIT, GC-2014 PCB CPU ASSY, GC2010
221-70065-91 221-70066-91
DOOR ASSY HEAT INSULATING MATERIAL,
DOOR ASSY
221-70353
DOOR
221-49609
HOOK, DOOR
221-49611
SHAFT, DOOR
221-70250-91
PCB KEY ASSY, GC-2014
221-70368
KEY COVER
221-48721-91
LCD ASSY
221-70244
LCD FILTER
221-70369
UNDER COVER
221-70725
TAPE WIRE
221-70070-91 221-45745-97
AFC UNIT PCB FLOW, I/F, GC2010
221-47663-01
FLAT CABLE, 34P
221-47653-91
POWER SWITCH ASSY
221-70515
FLOW CONTROLLER COVER
037-02820-57
KNOB, KNURLED, N-1, M4×8, WHITE
(A)

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
