Shimadzu GC-2014 Series User Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
17
221-70080-91 221-70189-91
PACKED DUAL INJ,100V INJECTION UNIT ASSY,122
115V:221-70080-92
230V:221-70080-34 221-70479-91 221-70484-91
HETER,PT ASSY,P-INJ100 HEATER, 100V/150W ASSY
115V:221-70479-92 115V:221-70484-92
230V:221-70479-34 230V:221-70484-34
221-44584 221-70596-91
GUIDE, FOR NEEDLE FIN, AOC HEAT SENSITIVE MATERIAL, INJ
221-70466 050-73001-79
FIN, 2014 R, RN AXIAL, 1/2W, 1802F
221-22206
SPACER, INJ
221-70090-91 221-70630-91 221-70298-91
FID-2014 CELL ASSY,P FID-2014 CELL BASE ASSY BASE, MAIN ASSY, FID
221-70162-92
NOZZLE ASSY, PACKED
221-47146-92
HIGH VOLTAGE ELECTRODE,
221-47659-92 FID2014
COLLECTOR ASSY, FID, 600MM
221-41847-93
FILAMENT ASSY, 180MM
221-70085-91 221-70671-91
DET HEATER ASSY,F,100V HEATER,PT ASSY,D-FID 100
115V:221-70085-92 115V:221-70671-92
230V:221-70085-34 230V:221-70761-34
221-70049-91 221-18150-91
FLOW CONTROLLER, N BELLOW VALVE, 2K
H2-AIR,FID
221-41511-91 221-41510
N BELLOW VALVE, 2K, METAL CAP, REPROCESSED,
WITH RESISTANCE WITH RESISTANCE
221-18150-91
670-18558-11 N BELLOW VALVE, 2K
PRESSURE GAUGE, 200KPA
221-70483-91
SOLENOID VALVE ASSY
042-40043-02
SPEED CONTROLLER, ASN-M5
221-31745
HOUSING
221-19502-08
RESISTANCE TUBE, HYDROGEN, GC-8A
201-47435
RUBBER PLUG, INJECTION PORT, SILICON
221-19503-08
RESISTANCE TUBE, AIR, GC-8AF
②
⑤
⑧
⑦

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
