Shimadzu GC-2014 Series User Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
18
221-70035-91 221-70082-91 221-47221-91
SPL-2014ASSY,100 SPL-2014UNIT,100-120 INJECTION PORT A AASY
115V:221-70035-91
115
Ｖ：
221-70082-91
230V:221-70035-34
230
Ｖ：
221-70082-98
221-70166-91
BASE, VAPORIZING CHAMBER A ASSY
221-70602-91 221-70599-91
HEATER, PT ASSY, SPL100 HEATER, 120/150W ASSY
115V:221-70602-91 115V:221-70599-91
230V:221-70602-34 230V:221-70599-34
221-70596-91
HEAT SENSITIVE
MATERIAL, INJ
050-73001-49
R, RN AXIAL, 1/2W, 1001F
221-47735-93
AFC-2014,D-PURGE,SPL
221-48440-93 221-42559-92
PIPING ASSY,AFC-SPL, FILTER ASSY, WITH BLIND
ADDITION
221-48441-91
BUFFER ASSY
221-34121-94
MS FILTER, CONDITIONING
221-48619-93
ACCESSORY ASSY,SPL-2014
⑨
221-70091-91 221-70090-91
FID-2014,100-120V FID-2014 CELL ASSY,P
115V:221-70091-91
230V:221-70091-98 221-70610-91 221-70087-91 221-70458-91
FID-2014 HETER ASSY,100 DET HEATER ASSY, HEATER PT ASSY,100V DET
115V:221-70610-91 SINGLE, 100V
230V:221-70610-34 115V:221-70087-91
230V:221-70087-34
050-73001-81
R, RN AXIAL, 1/2W, 2202F
221-46520-92
FID-2014 CONTROLLER
⑩⑤
221-70049-94 221-18150-93
FLOWCONTROLLER,AUX NBELLOWVALVE,2K,8KIN
670-18558-11
PRESSUREGAUGE,200KPA
221-31745
HOUSING
221-19502-08
RESISTANCETUBE,HYDROGEN,GC-8A
201-47435
RUBBERPLUG,INJECTIONPORT,SILICON
⑪

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
