Shimadzu GC-2014 Series User Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
19
*
221-70086-91 221-70671-91
DET HEATER ASSY,FT,100V HEATER,PT ASSY,D-FID 100
115V:221-70086-92 115V:221-70671-92
230V:221-70086-34 230V:221-70761-34
221-70098-91 221-70743-91 221-70741-91 221-70742-91
TCD-2014 CELL ASSY,100V HOT PLATE ASSY, 2014, 100V HEATER PT ASSY, TCD, 100 HEATER ASSY, 100V, 200W
115V:221-70098-91 115V:221-70743-91 115V:221-70741-91 115V:221-70742-92
230V:221-70098-34 230V:221-70743-34 230V:221-70741-34 230V:221-70742-34
221-32577-91 221-70740-91
PIPE ASSY, COL-TCD1 HEAT SENSITIVE
MATERIAL, TCD
221-32577-92
PIPE ASSY, COL-TCD2 050-73001-85
R, RN AXIAL, 1/2W, 3302F
221-70744-91
TCD, 100 OHMS, 2014
221-13964-91
PIPE, BENT
221-70043-91 074-80383-82
TCD POWER SUPPLY ASSY POWER SUPPLY, ZWS30-48/J
221-46229-94
PS CABLE, AC, AUX, 2014
221-70669-91
PS CABLE, TCD, DC
221-70952-91 221-34012-91
DETECTOR ADAPTER ASSY WBC, DET ADAPTER, WITH PURGE
221-15561-92
JOINT SET, DET ADAPTER
221-15563-91
GRAPHITE FERRULE, FOUR
⑮
⑰
⑳
⑭

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
