Valves group
3-14 MORPHEUS MRI
MAPLESON C adult patient circuit
• Connect the hose of supplied patient
circuit to the “AUX” connector on front
panel.
• Position the patient circuit on patient
circuit supporting arm.
MAN (MANUAL) operative mode:
• select the MAN operative mode on the
ventilator membrane key board;
• on front panel, press the “AUX”
membrane key (the green led lights
on);
• manage the quantity of fresh gases for
manual ventilation of the patient
through the gas flowmeter box.
