Product Description
GMS800 · Operating Instructions · 8013025 V1.2 · © SICK MAIHAK GmbH 17
Subject to change without notice
2.3 Product components
2.3.1 Enclosures
2.3.2 Control unit
Constructive version
Control unit integrated in enclosure.
Electronic function
Runs as independent electronic module.
Collects and displays measured values from other modules.
Includes the operating and display functions.
Controls I/O module outputs (
p. 18, §2.3.5).
Controls internal processes (e.g. adjustment procedure).
2.3.3 Analyzer modules
Analyzer module types
Type Intended use
GMS810 Installation in 19" rack or corresponding outer enclosure
GMS815P Wall assembly in industrial environment; variants:
–Standard version
“Vapor-proof” version for potentially explosive atmospheres
Versions with enclosure pressurization system for potentially explo-
sive atmospheres
GMS820P
[1]
[1] In preparation
Potentially explosive atmospheres zone 1
GMS830 Integration in system cabinets, for large modules
GMS831 Integration in system cabinets, for small modules
Detailed information and specifications
Supplementary Operating Instruc-
tions for Enclosure concerned
Detailed information
Operating Instructions for Control Unit
Analyzer module Measuring principle Measuring components, application
DEFOR UVRAS
[1]
/ UV-IFC
[1] For measuring component NO
1 to 3 UV measuring components
OXOR-E Electrochemical cell O
2
, standard requirements
OXOR-P Paramagnetism O
2
, high requirements
THERMOR Thermal conductivity H
2
, CO
2
, He and others
UNOR-MULTOR NDIR 1 to 4 IR measuring components
