18 GMS800 · Operating Instructions · 8013025 V1.2 · © SICK MAIHAK GmbH
Product Description
Subject to change without notice
2.3.4 Gas module
Possible components
● Gas pump
● Pressure sensor
● Flow sensor
● Moisture sensor
Electronics
The Gas module delivers measured values and status signals of the sensors in the same
manner as an Analyzer module.
2.3.5 I/O module
An I/O module makes the GMS800 signal connections available. The enclosure can hold 1
or 2 I/O modules (depending on device configuration).
2.3.6 Possible product configurations
Minimum configuration
● 1 power supply unit (provides operating voltage for internal modules)
● 1 control unit
● 1 Analyzer module with 1 measuring component
Maximum configuration
● 1 power supply unit
● 1 control unit
● 1 large Analyzer module (UNOR-MULTOR, DEFOR)
● 2 small Analyzer modules (OXOR-E, OXOR-P, THERMOR)
● 1 Gas module (gas pump, sensors)
● 1 or 2 I/O modules (per device configuration)
● Monitoring and controlling with PC + PC software “SOPAS ET”
Detailed information → Supplementary Operating Instructions “Gas Module”
Detailed information → Supplementary Operating Instructions “I/O Module”
The maximum configuration may be restricted for some enclosure types.
