1. Function
The Data Logger is a data collector for Stack TMS (Tele-Metering System). It is
important device as it is used for collecting data, and analyzing, storing them for
transmission to the connected server.
The Data Logger is able to execute the designated performance such as correction of
various measuring instruments from a host computer (Ministry of Environment’ s
server) by remote control when needed. The functions are as follows.
(1) Input/Output Function
Function
Description
ANALOG INPUT
(Signal Input)
ANALOG 4∼20 ㎃
DIGITAL INPUT
(For Status)
Up to connect 3 lines / Analog Channel
DIGITAL OUTPUT
(For calibration control)
Up to connect 5 lines / Analog Channel
Place for data output
transmission
Ministry of Environment (or FEP),
Tele-monitoring PC
Auto Dump Function
Over 2 hours
Analog Output
ANALOG 4∼20 ㎃
Remote Control
Remote calibration, remote search, time
adjustment and etc.
(2) Data Process Function
Function
Description
Data Collection Frequency
(AI Board)
Over 300 time/sec
Validity/invalidity of Data
Transmission
Process as regulated status by test method
Data Speed Selection
1200 ∼ 19200 bps
Parameter Set-up
Communication, time, calibration, channel and
etc.
COM. Port View
Check communication status
SIGNAL Process
AI, AO : 4∼20 ㎃
DI: Correction, out of order, power disconnection
DO: ZERO/SPAN Calibration etc.
