2. Configuration
Configuration of Data Logger is as follow.
UNIT name
Quantity
Remark
CPU Part
CPU BOARD (Including CPU & MAIN MEMORY)
1 EA
Refer to picture
SSD BOARD (Including ROM & FLASH MEMORY)
1 EA
Refer to picture
SERIAL / PARALLEL PORT
1 EA
P-COM BOARD
1 EA
I/O BOARD
AI BOARD
1 EA
8 or 16ch
AO BOARD
1 EA
8 or 16ch
DO BOARD
1 EA
16 or 32ch
DI BOARD
1 EA
16 or 32ch
DI BOARD (Option)
1 EA
16 or 32ch
Others
LCD
1 EA
KEYPAD
1 EA
POWER SUPPLY UNIT
1 EA
Refer to picture
RACK MOUNT SHASSIS
1 EA
[SSD BOARD] [CPU BOARD]
[I/O BOARD] [POWER SUPPLY]
