SICK DUSTHUNTER T User Manual

46 DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany
Assembly and Installation
MCU processor board connections
Figure 27 MCU processor board connections
Supply Connection for
voltage 24 V DC optional I/O module
RS232
Connections for relays 1 to 5
Connections for
analog inputs
1 and 2
Connection for
analog output
Connections for
digital inputs
1 to 4
Connection
for LEDs
Connection
for optional
Interface
module
USB plug
connector
Connection for optional
Display module
Connections for sender/
receiver unit
