Assembly and Installation
DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany 47
Standard connection
Figure 28 Standard connection
MCU processor board
Sender/receiver unit
Plug
Connection cable
(SICK cable or onsite cable
according to page 42, §3.3.1)
Operation/ malfunction Maintenance Check cycle Mainenance request Limit value
Socket
White Brown Green Yellow
White Yellow Green Brown
Plug assignment
(View on pin side)
RS485 B
3
RS485 A
4
5
6
-24 V
2
7
1
+24 V
Switching position of the relay contacts
in currentless condition
