SPECIFICATIONS 9
9.3 Modbus Register Mapping
9.3.1 Mapping of GM32 measuring components
● Modbus register for 16 components
● Address, address start and address end of further components (component 4,
component 5, ...) are each incremented with 17, the sequence of the items remains
the same.
● The sequence of the components depends on the GM32 configuration.
Name Item Address Data type Register type Comment
Start Width
Measured Value 5000 2 32 Bit float Input register Measuring value
Status 5002 1 16 Bit integer Input register Status
0)
Zero Point Value 5003 2 32 Bit float Input register Zero point
Span Point Value 5005 2 32 Bit float Input register Span point
Start of measuring range 5007 2 32 Bit float Input register min of range
End of measuring range 5009 2 32 Bit float Input register max of range
Regression coefficient C0 5011 2 32 Bit float Input register Offset
Regression coefficient C1 5013 2 32 Bit float Input register Slope
Regression coefficient C2 5015 2 32 Bit float Input register Correction factor
Measured Value 5017 2 32 Bit float Input register Measuring value
Status 5019 1 16 Bit integer Input register Status
0)
Zero Point Value 5020 2 32 Bit float Input register Zero point
Span Point Value 5022 2 32 Bit float Input register Span point
Start of measuring range 5024 2 32 Bit float Input register min of range
End of measuring range 5026 2 32 Bit float Input register max of range
Regression coefficient C0 5028 2 32 Bit float Input register Offset
Regression coefficient C1 5030 2 32 Bit float Input register Slope
Regression coefficient C2 5032 2 32 Bit float Input register Correction factor
Measured Value 5034 2 32 Bit float Input register Measuring value
Status 5036 1 16 Bit integer Input register Status
0)
Zero Point Value 5037 2 32 Bit float Input register Zero point
Span Point Value 5039 2 32 Bit float Input register Span point
Start of measuring range 5041 2 32 Bit float Input register min of range
End of measuring range 5043 2 32 Bit float Input register max of range
Regression coefficient C0 5045 2 32 Bit float Input register Offset
Regression coefficient C1 5047 2 32 Bit float Input register Slope
Regression coefficient C2 5049 2 32 Bit float Input register Correction factor
Table 27: Modbus component register (for the first 3 components)
