73
8012707/ZVF9/V2-1/2019-04 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
SPECIFICATIONS 9
9.3.8 Bitmap Table “Extended”
Additional functions, such as alarm functions are listed in Bitmap Table.
9.3.9 Table “Operating States”
Bit No. Name Comment
0 Alarm purge air Bit=1: active
1 Alarm optic housing temperature Bit=1: active;
2 Alarm lamp current Bit=1: active;
3 Alarm lamp integration Bit=1: active;
4 Alarm pressure (pressure < 800 hPa or pressure > 1300 hPa) Bit=1: active
5-31 Reserved
Table 34: Bitmap Table for extended functions
Value Operating state
0 not defined
1 Initialisation
2 Measuring
3 Maintenance
4 RCycle
5 Check cycle
6 ZeroAdjust
7 Alignment
8 Boxmeasuring
9 Restart
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
16 Reserved
17 Reserved
18 Reserved
19 Reserved
20 Reserved
Table 35: Table “Operating states”
