SICK GM32 Series User Manual

72
8012707/ZVF9/V2-1/2019-04 | SICKOPERATING INSTRUCTIONS | GM32
Subject to change without notice
9 SPECIFICATIONS
9.3.5 Bitmap Table “Failure”
9.3.6 Bitmap Table “Maintenance Request”
9.3.7 Bitmap Table Function “Check” and “Out of Specification”
The “Function Check” and “Out of Specification” is currently not defined
Bit No. Name Comment Bit No. Name Comment
0 EEPROM Bit=1: active 16 File config Bit=1: active
1 Spectro com. Bit=1: active 17 File conditions Bit=1: active
2 Zero com. Bit=1: active 18 File espec Bit=1: active
3 Extinction calc Bit=1: active 19 File cact Bit=1: active
4 Reference calc Bit=1: active 20 Visor com. Bit=1: active
5 IIR Filter Bit=1: active 21 Lamp com. Bit=1: active
6 Interpolation Bit=1: active 22 Spectro para. Bit=1: active
7 Filter com. Bit=1: active 23 Eval modul com. Bit=1: active
8 Mirror com. Bit=1: active 24 Purge air signal Bit=1: active
9 Visor fault Bit=1: active 25 Temp control com. Bit=1: active
10 Visor values Bit=1: active 26 Temp control out of range Bit=1: active
11 Zero adj. mc adj. Bit=1: active 27 Failure eval module Bit=1: active
12 Lamp fault Bit=1: active 28 MV failure activ Bit=1: active
13 Visor no signal Bit=1: active 29 Reserved Bit=1: active
14 Mirror adj. End Bit=1: active 30 Reserved Bit=1: active
15 File measval Bit=1: active 31 Reserved Bit=1: active
Table 31: Bitmap “Failure”
Bit No. Name Comment Bit No. Name Comment
0 Lamp performance Bit=1: active 16 Check Cycle cell empty Bit=1: active
1 Lamp minimum parameter Bit=1: active 17 Temp control voltage low Bit=1: active
2 Lamp 4Q max parameter Bit=1: active 18 Temp control lamp fan Bit=1: active
3 Data logging: writing data Bit=1: active 19 Temp control optic fan Bit=1: active
4 Data logging: open file Bit=1: active 20 Temp control spectro fan Bit=1: active
5 Temp. Extern Bit=1: active 21 Temp control electronic temp Bit=1: active
6 Flashcard missing Bit=1: active 22 Temp control spectro temp Bit=1: active
7 Logbook error Bit=1: active 23 Lamp performance limit Bit=1: active
8 IO com. Bit=1: active 24 Probe message Bit=1: active
9 IO error Bit=1: active 25 Reserved Bit=1: active
10 Spectro no answer Bit=1: active 26 Reserved Bit=1: active
11 Check Cycle span drift Bit=1: active 27 Reserved Bit=1: active
12 Check Cycle zero drift Bit=1: active 28 Reserved Bit=1: active
13 Check Cycle wavelength drift Bit=1: active 29 Reserved Bit=1: active
14 Check Cycle peak position Bit=1: active 30 Reserved Bit=1: active
15 Check Cycle peak width Bit=1: active 31 Reserved Bit=1: active
Table 32: Bitmap “Maintenance Request”
Bit No. Name Comment
0 -31 not specified Bit=1: active
Table 33: Bitmap Table for “Function Check” and “Out of Specification”
