8012707/ZVF9/V2-1/2019-04 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
SPECIFICATIONS 9
9.2.3 Sender/receiver unit
9.2.4 Open measuring probe (GMP)
9.2.5 Gas-testable measuring probe (GPP)
Description Analyzer unit of the measuring system
Operation Via integrated control unit
Dimensions (W x H x D) 315 mm x 580 mm x 359 mm
Weight 20 kg
Table 22: Technical data sender/receiver unit
Description
Measuring probe in open design version with integrated purge air
guidance system
Process temperature
≤ +550 °C
Versions for higher temperatures on request
Process pressure
–60 hPa ... 60 hPa
Relative
Dimensions (W x H x D) See dimension drawings
Weight 25 kg
Material, media contact Stainless steel 1.4571, stainless steel 1.4539
Auxiliary gas connections Purge air
Built-in components
Pressure sensor (not in Ex version)
Temperature sensor PT1000 (not in Ex version)
Flow monitor (purge air feed monitor, not in Ex version)
Table 23: Technical data open measuring probe (GMP)
Description
Measuring probe with gas permeable filter element for adjustment
with test gas
Process temperature
With ceramic filter: ≤ +430 °C
With teflon filter: ≤ +200 °C
Process pressure
–60 hPa ... 60 hPa
Relative
Dimensions (W x H x D) See dimension drawings
Weight 45 kg
Material, media contact Stainless steel 1.4571, stainless steel 1.4539, ceramic, PTFE
Power supply
Voltage
Frequency
Power input
115 V / 230 V
50 Hz / 60 Hz
≤ 150 W
Auxiliary gas connections
Test gas
Purge air
Built-in components
Pressure sensor
Temperature sensor PT1000
Table 24: Technical data gas-testable measuring probe (GPP)
