7
8012707/ZVF9/V2-1/2019-04 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
ABOUT THIS DOCUMENT 1
1.1.3 Information symbols
1.2 Main instructions for operation
1.3 Intended use
1.3.1 Purpose of the device
The GM32 serves exclusively for emission and process monitoring of gases in industrial
plants.
GM32 measures continuously directly in the gas duct (in-situ).
1.4 Product identification
1.5 Responsibility of user
Designated users
The GM32 may be operated by competent persons only who, based on their device-specific
training and knowledge of the device as well as knowledge of the relevant regulations, can
assess the tasks given and recognize the dangers involved.
Symbol Significance
Important technical information for this product
Important information on electric or electronic functions
WARNING: Danger resulting from escaping gas when the SR-unit is swiveled
out
Excess pressure in the gas duct can cause hot and/or noxious gases to escape when
the SR-unit is swiveled out.
▸ Swivel the SR-unit out only when you have taken suitable safety measures.
CAUTION: If the hinge pin has not been correctly inserted, the SR-unit can
drop when swiveled out.
▸ Check the hinge pin is completely pressed down before swiveling the SR-unit out (see
“Install the SR-unit:”, page 36).
CAUTION: Danger of contamination caused by purge air failure (for GM32 with
GMP probe)
▸ If a failure of the purge air supply occurs, take immediate measures to protect the
measuring system (see “Error messages”, page 56).
Product name GM32
Product variant Version with measuring probe
Manufacturer
SICK AG · Erwin-Sick-Str. 1
D-79183 Waldkirch · Germany
Location of type plates
Sender/receiver unit: On the right side and on the intermediate
enclosure
Connection unit: On the right side and inside
For GMP probe: On the purge air fixture
For GPP probe: On the flange fixture
