9 SPECIFICATIONS
9.3.2 Mapping for GM32 in general
● Modbus register for output signals, valid for all measured components
Item Address Data type Register type Comment
Start Width
Year of current date 5272 1 16 Bit integer Input register > 2000
1)
Month of current date 5273 1 16 Bit integer Input register 1 – 12
1)
Day of current month 5274 1 16 Bit integer Input register 1 – 31
1)
Hour of current time 5275 1 16 Bit integer Input register 0 – 23
1)
Minute of current time 5276 1 16 Bit integer Input register 0 – 59
1)
Second of current time 5277 1 16 Bit integer Input register 0 – 59
1)
Failure [collective] 5278 2 32 Bit integer Input register Bit Field
2)
Maintenance required
[collective]
5280 2 32 Bit integer Input register Bit Field
3)
Check [collective] 5282 2 32 Bit integer Input register Bit Field
4)
Out of Spec. [collective] 5284 2 32 Bit integer Input register Bit Field
5)
Extended [collective] 5286 2 32 Bit integer Input register Bit Field
6)
Pressure 5288 2 32 Bit float Input register
Temperature 5290 2 32 Bit float Input register
Humidity 5292 2 32 Bit float Input register
Lamp Current 5294 2 32 Bit float Input register Lamp pulse (mA)
Lamp Integration 5296 2 32 Bit float Input register Exposure (ms)
Temperature Optic Housing 5298 2 32 Bit float Input register
Temperature Spectrometer 5300 2 32 Bit float Input register
Lamp performance 5302 2 32 Bit float Input register
Operating state 5304 1 16 Bit integer Input register 8)
Year of last Check cycle 5305 1 16 Bit integer Input register > 2000
9)
Month of last Check cycle 5306 1 16 Bit integer Input register 1 – 12
9)
Day of last Check cycle 5307 1 16 Bit integer Input register 1 – 31
9)
Hour of last Check cycle 5308 1 16 Bit integer Input register 0 – 23
9)
Minute of last Check cycle 5309 1 16 Bit integer Input register 0 – 59
9)
Second of last Check cycle 5310 1 16 Bit integer Input register 0 – 59
9)
LED Current 5311 1 16 Bit integer Input register 0 - 200 (mA)
LED performance 5312 1 16 Bit integer Input register 0 - 100 (%)
Table 28: Modbus “Common Out” register
