START-UP 4
4.15 Installing weatherproof covers (option)
Fig. 22: Weatherproof cover of sender/receiver unit
2 steps are necessary to fit the weatherproof cover:
1 Install the installation plate on the flange of the purge air fixture.
Fig. 23: Weatherproof cover
▸ Lay the weatherproof cover upside down on the floor.
▸ Open and unhinge the locks on both sides.
▸ Pull the installation plate upwards and remove it from the cover.
Lock
Mounting ring
Installation plate
