SICK GM32 Series User Manual

71
8012707/ZVF9/V2-1/2019-04 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
SPECIFICATIONS 9
9.3.3 Mapping of Modbus input values
● Modbus register for input signals, valid for all measured components
0)
Bit field, please see Table "Status" for details, see “Bitmap “Status””, page 71.
1)
Current date and time of the device in ISO8601 format.
2)
Bit field, please see Table “Failure” for details, see “Bitmap “Failure””, page 72
3)
Bit field, please see Table “Maintenance request” for details, see “Bitmap “Maintenance
Request””, page 72
4)
Bit field, please see Table “Function check” for details, see “Bitmap Table for “Function
Check” and “Out of Specification””, page 72.
5)
Bit field, please see Table “Out of Spec” for details.see “Bitmap Table for “Function
Check” and “Out of Specification””, page 72
6)
Bit field, please see Table “Extended” for details, see “Bitmap Table for extended func-
tions”, page 73
8)
For Table of operating states please see Table “Operating states” for details, see “Table
“Operating states””, page 73
9)
Date and time of last control check cycle for all components of the GM32
10)
Sticky: functions like a switch
11)
Momentary: functions like a push button
9.3.4 Table Bitmap “Status”
Item Address Data type Register type Comment
Start Width
Pressure 6000 2 32 Bit float Holding register
Temperature 6002 2 32 Bit float Holding register
Humidity 6006 2 32 Bit float Holding register
Password 6900 3 string Holding register
Pressure valid flag 6000 1 1 Bit Coil sticky
10)
Temperature valid flag 6001 1 1 Bit Coil sticky
10)
Humidity valid flag 6002 1 1 Bit Coil sticky
10)
Maintenance switch 6003 1 1 Bit Coil sticky
10)
Trigger control cycle 6004 1 1 Bit Coil momentary
11)
Supress control cycle 6005 1 1 Bit Coil sticky
10)
Table 29: Modbus input register
Bit No. Name Comment Bit No. Name Comment
0 Failure Bit=1: active 8 Check cycle Bit=1: active
1 Maintenance request Bit=1: active 9 Reserved Bit=1: active
2 Function Check Bit=1: active 10 Reserved Bit=1: active
3 Out of Spec Bit=1: active 11 Reserved Bit=1: active
4 Extended Bit=1: active 12 Reserved Bit=1: active
5 Under range Bit=1: active 13 Reserved Bit=1: active
6 Over range Bit=1: active 14 Reserved Bit=1: active
7 Maintenance Bit=1: active 15 Reserved Bit=1: active
Table 30: Bitmap “Status”
